A case of Gas Field Cluster Development Project of a Large Central Enterprise
Project Brief
The project includes the construction of a new central platform, a set of subsea production system and three subsea pipelines, and the modification works of 8-3 WHPB platform (including riser installation and platform renovation). It is a project with large investment scale and high complexity, the construction of the project will be a large-scale and multi-level system engineering, which requires timely and accurate information exchange, coordination and communication.
The upper platform is 83 meters long and 40 meters wide, with an area equivalent to eight basketball courts. The height is 53 meters, equivalent to the height of a 15-storey building. And its weight is 12800 tons, equivalent to the weight of a light aircraft carrier.
Challenges Ahead
Characteristics of offshore oil industry
The project is with short time limits
Design phase and construction phase overlap
Construction changes are frequent and it will lead to low efficiency
Waiting for drawings and materials on the site will lead to work delays
Operation Status
The report is input by manual
Resource sharing is difficult to achieve
The workload of manual input is huge
The dynamic information is not accurate
EPC's Solution
A set of 4D5D visual smart management system which meets the actual needs of the project, will closely integrate the design, procurement, logistics, material management, construction, and commissioning processes and support the collaboration work with subcontractors.
Visual Smart Project Management Platform-VSP
Project Communication and Document Management-EPC DOC
Material Management-EPC MAT
Progress Management- EPC PPS
Quality Management-Q Man
Commissioning Management-MECHS
Application Value
Visual progress simulation of work scope, visual smart deduction of progress and problems
Cost
Optimize the construction plan, reduce rework and purchase errors
Progress
  • Reduce the progress delay caused by the late arrival of materials and drawings
  • Early warning of schedule delays and late arrival of materials/equipment
  • Optimize the construction plan according to the arrival of equipment
  • Arrange the commencement work reasonably
Communication
The information communication between different sections is more direct, intuitive efficient. The accumulation of project information provides the basis for the company-level big data analysis standards
